American Version AC Charging Pile

The American version of AC charging pile refers to charging piles that are designed and manufactured according to the standards and specifications of the United States, and are mainly used to charge electric vehicles in the United States. The American version of AC charging pile support AC charging, which is a slower but more widespread charging method compared to DC charging. AC charging piles can be installed in various locations, such as homes, parking, and public charging stations to provide convenient charging solution.

Send Inquiry

Description

The American version of AC charging pile specification:

Items	Parameters
Design standard	EN62196; IEC62196; IEC61851; EN61851; SAEJ1772; UL2594; UL2231
Charging mode	Mode 2
Power system	TN-C, TN-S
Rated input voltage	220V-240VAC
Rated output voltage	220V-240VAC
Rated charging current (adjustable)	8A/10A/13A/16A
Operating frequency	50Hz/60Hz
Rated remaining working current	30mA+DC6mA
CP Signal	1KHz±30Hz, ±12V
Standby Power	<2W
Operating temperature/humidity	-35°C-50°C/5%-95%
Storage temperature	-40°C-80°C
Insulation resistance	>10MQ
Control box protection level	IP68
Protection level of charging gun	IP65
Security protection	Product overtemperature protection, relay fault detection, over-current protection, over-voltage protection, under-voltage protection, leakage protection, plug temperature protection, ungrounded protection, short circuit protection, equipment/connection abnormal protection, charging system abnormal protection
Crush strength	≤11000N
Impact withstand voltage	≤2.5KV
Service life	10000 times
Flame retardant grade	UL94-V0
Working altitude	≤2000M
Control box size (mm)	L200xW80xH50
Gun body size (mm)	L200xW136xH65
Line length	On Demand

Selling Points

Compatibility: Widely compatible with a wide range of popular electric car models in the US market, ensuring easy access for owners of different brands. Supports US standard voltage and current, no need to worry about power mismatch.

Safety: Equipped with multiple safety protection functions, such as over-current protection, over-voltage protection, leakage protection, etc., to ensure a safe and reliable charging process.

Complies with relevant U.S. safety standards and certifications, such as UL (Underwriters Laboratories) certification, providing extra peace of mind.

Charging Speed: Although AC charging is slower compared to DC charging, The American version of AC charging piles may provide higher charging power and shorten charging time.

Supports smart charging management, which can automatically adjust the charging rate to optimize charging efficiency based on the vehicle's needs.
