Parameter list
|
Model |
electric utv for adults |
|
Certification |
EEC5 |
|
Loading information |
8units/20″;; 24units/40HQ |
|
Engine type |
4 - stroke,Single - Cylinder, Water - cooled |
|
Horse Power |
18KW ( 6500rpm) 25HP |
|
Valve Configuration |
SOHC |
|
Fuel Delivery System |
E5 EFI |
|
Choke System |
Automatic |
|
Fuel capacity |
9.5L (2.1 Gallon) |
|
Driveline Type |
4X2 |
|
Transmission |
CVT |
|
Final Drive |
Shaft - drive 2WD |
|
Starting system |
Electric start |
|
Ignition system |
D.C.D.I |
|
Suspension Front |
Double A - arm Suspension |
|
Suspension Rear |
Fang power 4 - Link® bar Rear Suspension |
|
Brakes Front&Rear |
220MM Front Dual Hydraulic Disk |
|
Front Tread |
1250mm ( 49.2 in) |
|
Rear Tread |
1150mm ( 45.2in) |
|
Wheelbase |
1980mm (78in) |
|
Ground clearance |
300mm(11.8in) |
|
Tire(F/R) |
25x8 - 12 / 25x10 - 12 |
|
Top speed |
75km/h |
|
Dry weight |
380kg |
|
Gross weight |
480kgs |
|
Vehicle dimension(L×W×H) |
2700x1450x1750mm |
|
Packing size |
2290x1400x815mm |
|
COLOR |
Red/Blue/ Orange/Green |
|
Steel Roof&door |
Standard |
|
windshield |
Standard |
|
Full bumper |
Standard |
|
Roof light bar |
Standard |
The agile off-road fairy
The agile off-road fairy: With its compact and agile body design, it can freely navigate through complex off-road tracks or narrow forest paths like a fairy, easily handling all kinds of tricky road conditions and bringing the driver ultimate driving pleasure.
Competitive-level power performance
The electric utv for adults, with its specially tuned engine and transmission system, delivers direct and powerful power output. It can reach a high speed in a short time and has abundant explosive power, making it a strong competitor in off-road competitive races.
Personalized appearance customization
electric utv for adults offers a rich variety of body color options. At the same time, it supports users to customize body stickers, wheel hub styles, seat materials, etc., making each FX400-2 PREDATOR unique and highlighting the owner's personality.
Product usage scenarios：
1. Small-scale site operations: orchards, small farms, etc., can quickly transport fruits and agricultural supplies, improving work efficiency.
2. Off-road racing: On small off-road tracks, with flexible handling and speed advantages, it brings thrilling competitive experiences to drivers.
3. Scenic Area Patrol: Patrolling the narrow roads within the scenic area enables quick access to various regions, ensuring the safety and order of the scenic area.
Product knowledge
1. Power system: 4-stroke single-cylinder water-cooled engine, featuring a lightweight aluminum alloy cylinder block, which reduces the overall weight of the engine without affecting its strength and durability. The power output is 15.2KW (20.4HP), reaching its peak at 7000rpm, with a rapid power response. The equipped fuel pump and vacuum diaphragm carburetor have been precisely calibrated to provide the engine with a mixture of appropriate concentration under different working conditions, ensuring the stable operation of the engine.
2. Transmission and Braking: The 4X2 drive mode, in combination with the shaft transmission system, ensures efficient and reliable power transmission. The CVT continuously variable transmission system is easy to operate and can automatically adjust the transmission ratio according to driving needs, achieving smooth acceleration and deceleration. Both the front and rear are equipped with a 220MM dual hydraulic disc brake system. The brake discs are designed with ventilation holes, providing excellent heat dissipation performance. This effectively avoids thermal fade during continuous braking, ensuring the sensitivity and reliability of braking.
3. Body and Suspension: The electric utv adopts a frame welded with high-strength steel pipes, featuring a compact and sturdy structure. The vehicle is compact in size and has an extremely small turning radius, enabling flexible steering even in narrow Spaces. The front double A-arm suspension and the rear Fang power 4-Link ® bar suspension system are tuned to be relatively firm, providing excellent support for the vehicle. During high-speed driving and intense handling, they can effectively suppress the body roll and ensure driving stability.
F&Q:
Q1: What is the maximum speed that the Gasoline electric utv for adults can reach?
A: Under ideal road conditions, the top speed of this vehicle can reach 75km/h, providing drivers with an exciting driving experience.
Q2: How is the handling flexibility of a vehicle reflected?
A: The compact and small body design, combined with the precisely tuned steering system, makes its turning radius extremely small. It can turn quickly and flexibly in narrow Spaces and complex terrains, easily handling various road conditions.
Q3: Is personalized modification supported?
A: Support! The Buggy SSV electric utv for adults reserves a wealth of modification interfaces. Users can install high-performance shock absorbers, upgrade the audio system, replace personalized body stickers, etc. according to their needs to create an exclusive vehicle.
