Parameter list
|
Model |
Micro scale trucks | |
|
Vehicle number |
W1600-1 |
W1600-2 |
|
Drive form |
4×2 |
|
|
Wheel Base(mm) |
2850/3070 |
|
|
Dimensions inside the cargo compartment(mm) |
3150/3600×1750×380 |
|
|
GVW(kg) |
3500 |
3500 |
|
Curb Weight(kg) |
1214 |
1210 |
|
Body Width(mm) |
1600 |
|
|
Cab Type |
Single Cab |
|
|
Fuel |
Gasoline |
|
|
Engine Model |
DAM-1.5 |
LJ469 |
|
Engine Manufactor |
Dongan Automobile Power Co., Ltd. |
LJ Power |
|
Displacement(ml) |
1.499L |
1.206L |
|
Emission |
EURO I/ Vi |
EURO I/ Vi |
|
Power (hp)/RPM |
112 |
82/5600rpm |
|
Torque(Nm/rpm) |
146N·m/3800rpm |
116N·m/3600~4000rpm |
|
Transmission model |
DAT18R |
|
|
Transmission manufacturer |
Dongan |
|
|
Front axle bearing capacity |
1.5T |
|
|
Middle/rear axle bearing capacity |
2T |
|
|
Drive axle speed ratio |
4.875 |
|
|
Braking type |
Oil brake |
|
|
Braking form |
Front plate and back drum |
|
|
Brake control system |
LSPV/ABS/ABS+ESC |
|
|
Tire model |
175R14(4/6+1) |
|
|
Number of tires |
4/6+1 |
|
|
Fuel tank capacity |
70L |
|
|
Number of leaf springs (front/rear) |
---or 3/5 |
---or 3/Big size level for cargo box in mini truck segme |
Environmental Compliance
Complies with the Euro VI emission standard, enabling users to operate in areas with strict environmental protection requirements and reducing pollution.
Diverse Power Options
Offers two engine models, DAM - 1.5 and LJ469. Users can choose according to different transportation needs, and the power output can meet the working conditions of small - scale cargo transportation.
Flexible and Compact
With a body width of 1600mm, it has a small turning radius, facilitating passage on narrow urban roads and benefiting distribution operations.
Practical Load - bearing Capacity
With a maximum gross vehicle weight of 3500kg, the rated load capacity can meet the transportation of goods around 1.2 tons, and the micro scale trucks cargo compartment size is suitable for daily small - scale cargo loading.
Key Advantages：
Diverse Engine Choices: Compared with similar mini - trucks, there are two engine options from Dongan and LJ Power, adapting to different users' needs for power and cost.
Adaptable Cargo Compartment Dimensions: The internal dimensions of the micro scale trucks cargo compartment have different specifications corresponding to wheelbases of 2850/3070mm, which can flexibly handle goods of different lengths.
Braking System Configuration: Some are equipped with LSPV/ABS/ABS + ESC braking control systems, providing better braking safety guarantees on mini - trucks than some competitors with only basic braking.
Optimized Curb Weight: The curb weights of different vehicle numbers vary, and users can choose according to operational needs (such as valuing light weight or load - bearing stability more), with high flexibility.
F&Q
Q: How about the fuel consumption of this micro scale trucks?
+
-
A: There are slight differences due to different engines (DAM - 1.5 and LJ469). Overall, it is at an economic level among similar gasoline mini - trucks. Under normal urban distribution conditions, the fuel consumption per 100 kilometers is probably around 8 - 10L (affected by driving habits and load).
Q: Can it enter the urban area for distribution?
-
A: It meets the Euro VI emission standard. As long as the local traffic policy for vehicles meeting this emission standard allows it and the vehicle size is within the traffic restrictions of urban roads, it can enter the urban area for distribution.
Q: Is the post - sales maintenance convenient?
-
A: The manufacturers of key components such as the engine (Dongan, LJ Power) have many after - sales outlets in China, and the supply of spare parts is relatively sufficient, so the convenience of maintenance is guaranteed.
Q: Can the cargo compartment be modified?
-
A: Without changing the overall structural safety and compliance of the vehicle, some functional modifications can be made to the cargo compartment (such as adding guardrails, compartments, etc.). However, it is necessary to consult the local vehicle management office and modification factory in advance to ensure compliance with regulations
A: Without changing the overall structural safety and compliance of the vehicle, some functional modifications can be made to the cargo compartment (such as adding guardrails, compartments, etc.). However, it is necessary to consult the local vehicle management office and modification factory in advance to ensure compliance with regulations
