Product Overview
Our factory's new Light Duty Diesel Box Truck is a 4×2 diesel commercial vehicle, which plays an important role in urban logistics distribution and cargo transportation.
This vehicle is specially designed for fleet buyers, distributors, logistics operators and other groups. It has been recognized by customers in the international market. Relying on our factory's complete vehicle manufacturing capacity, we design and produce high-quality and regulation-compliant vehicles for customers.
Parameters
|
Model |
FC36 |
||
|
Drive form |
4×2 |
4×2 |
4×2 |
|
Wheel Base(mm) |
3360 |
3800 |
4200 |
|
Overall dimensions of the vehicle (chassis)(mm) |
Chasis：5960×2076×2280 flatbed truck：5995×2200×2380 |
Chasis：6930×2076×2290 flatbed truck：6965×2270×2350 |
Chasis：7335×2195×2345 flatbed truck：7445×2370×2400 |
|
Dimensions inside the cargo compartment(mm) |
4170×2100×400 |
5140×2100×550 |
5600×2200×550 |
|
GVW(kg) |
7500 |
||
|
Body Width |
1900 |
||
|
Seats |
3 |
||
|
Fuel |
Diesel |
||
|
Displacement(ml) |
3760 |
||
|
Emission Way |
SCR |
||
|
Power (hp)/RPM |
115/2600 |
||
|
Torque(Nm/rpm) |
550/1200-1900 |
||
|
Transmission model |
ZF6S558 |
||
|
Front axle bearing capacity |
2.85T |
||
|
Drive axle speed ratio |
4.3 |
||
|
Braking type |
Air brake |
||
|
Braking form |
Front plate and back drum |
||
|
Brake control system |
ABS+ESC |
||
|
Tire model |
Tubeless radial tire (metric) 215/75 R17.5-14 |
||
|
Fuel tank capacity |
120L |
||
|
Suspension form |
Front and rear steel plate spring suspension |
||
|
Number of leaf springs (front/rear) |
3/7+6 |
||
|
Frame section |
214×65×5 |
||
Product Advantages
Strong power, easy to carry heavy cargo
The Light Duty Diesel Box Truck Equipped with a 3.76L diesel engine. Compared with gasoline-powered ones, it reduces refueling costs while maintaining power. The peak torque of the vehicle is 550 N·m, which enables the vehicle to output high torque even at low speed and handle various complex and rough road conditions perfectly. The vehicle is also equipped with a Selective Catalytic Reduction (SCR) emission system, which not only meets the strict emission standards in different regions but also improves fuel efficiency. It ensures your vehicle has a long service life and low maintenance costs.
Flexible cargo box configuration to meet different cargo needs
The cargo box is available in multiple wheelbases, including 3360mm, 3800mm and 4200mm. Both the size and material can be customized according to your actual needs and application scenarios.
Reinforced chassis and suspension system for stable driving
Adopting frame profiles of heavy-duty vehicles, the high-quality requirements make the Light Duty Diesel Box Truck reach the level of heavy-duty vehicles.
Both the front and rear axles are equipped with leaf spring suspension with a load capacity of 2.85 tons, which meets most cargo load requirements and improves the durability of the vehicle.
Tested braking and control system for driving safety
The Light Duty Diesel Box Truck Equipped with air brake system, integrated Anti-lock Braking System (ABS), Electronic Stability Control (ESC) and other safety systems to provide protection for emergencies during driving.
Equipped with 215/75 R17.5 tubeless radial tires, which have better grip than ordinary tires and greatly reduce the risk of tire blowout.
Application Scenarios
Thislight duty box truck has a wide range of applications, including:
Urban and surrounding logistics distribution
E-commerce and courier fleet transportation
Cold chain transportation (refrigerated cargo box optional)
Supply chain transportation in retail and wholesale industries
Manufacturing Process and Technical Strength
The whole light duty commercial truck production adopts automotive-grade stamping, robotic welding, painting and assembly lines throughout the process. Core components such as the frame and body are independently developed to ensure dimensional accuracy and consistent quality control.
After-sales Service and Technical Support
Provide a full set of technical documents and remote technical support.
Create a long-term cooperation model for overseas partners.
FAQ
Q1: Can this light duty diesel box truck for sale be customized into other special vehicles?
A: Yes. We support the customization of refrigerated and insulated cargo boxes, and can also create exclusive special configurations according to logistics needs.
Q2: Is this model suitable for the overseas market?
A: Yes. The whole light duty box truck for city distribution is designed for export with flexible and adjustable configurations. For details, please consult us.
Q3: What advantages does this 7.5 ton light duty box truck have in later maintenance?
A: The diesel powertrain has mature technology and a complete supporting system, which greatly improves the durability of the vehicle and reduces maintenance costs.
