Parameter list
|
Model |
utility side by side |
|
Certification |
EPA |
|
Loading information |
2units/20″;; 12units/40HQ |
|
Engine type |
4 - stroke,Single - Cylinder, Water - cooled |
|
Horse Power |
18KW ( 6500rpm) 25HP |
|
Valve Configuration |
SOHC |
|
Compression ratio |
10.0:1 |
|
Fuel Delivery System |
EFI |
|
Choke System |
Automatic |
|
Fuel capacity |
9.5L (2.1 Gallon) |
|
Driveline Type |
4X2 |
|
Transmission |
CVT |
|
Final Drive |
Shaft - drive |
|
Starting system |
Electric start |
|
Ignition system |
D.C.D.I |
|
Suspension Front |
Double A - arm Suspension |
|
Suspension Rear |
Fang power 4 - Link® bar Rear Suspension |
|
Brakes Front&Rear |
220MM Front Dual Hydraulic Disk |
|
Front Tread |
1250mm ( 49.2 in) |
|
Rear Tread |
1150mm ( 45.2in) |
|
Wheelbase |
2800mm |
|
Ground clearance |
300mm(11.8in) |
|
Tire(F/R) |
25x8 - 12 / 25x10 - 12 |
|
Top speed |
75km/h |
|
Dry weight |
480KGS |
|
Gross weight |
540kgs |
|
Vehicle dimension(L×W×H) |
3360x1450x1750mm |
|
Packing size |
2980x1400x815mm |
|
COLOR |
Red/Blue/ Orange/Green |
|
Steel Roof&door |
Standard |
|
windshield |
Standard |
|
Full bumper |
Standard |
|
Roof light bar |
Standard |
The king's choice for heavy-duty transportation
With its super-large capacity cargo boxes and extremely strong carrying capacity, it has become a leader in the field of heavy-duty transportation. Whether it is the transportation of sand, gravel and cement at construction sites or the handling of agricultural products on farms, they can all be handled with ease, greatly improving work efficiency.
Outstanding stability
The ultra-long wheelbase and optimized suspension system make the vehicle as stable as Mount Tai during driving. Even when fully loaded on bumpy roads, it can effectively reduce the jolting and damage of goods, ensuring the safety and integrity of transportation.
Durability and reliability
All key components of the vehicle are made of high-quality materials and have undergone strict quality inspection and durability tests. Even in harsh working environments, it can still operate stably for a long time, reduce the frequency of faults, lower maintenance costs, and is a reliable partner for long-term high-intensity use.
Product usage scenarios
1. Large-scale farm operations: Factory Direct utility side by side is used for transporting large quantities of agricultural products and feed, and for the allocation of materials for large-scale farmland operations.
2. Engineering construction: Transporting building materials at construction sites and ores in mines, etc., to adapt to harsh engineering environments.
3. Field exploration: Equipped with exploration equipment, it can travel stably in complex terrains in the wild, providing support for exploration work.
Product knowledge
1. Power system: The utility side by side is equipped with a 4-stroke single-cylinder water-cooled engine, which has the characteristic of high torque output. It can output powerful torque in the low-speed range and easily handle working conditions such as heavy load climbing. With a power of 18KW (25HP) and a compression ratio of 10.0:1, the power reserve is sufficient. Adopting the advanced EFI fuel injection system, it can intelligently adjust the fuel injection volume according to the vehicle's load and driving conditions, ensuring the efficient operation of the engine and reducing fuel consumption.
2. Chassis and Load-bearing: The utility side by side adopts the same high-strength beam-type frame as heavy-duty trucks, which has undergone special thickening treatment and can withstand huge load pressure. The ultra-long wheelbase design not only enhances the vehicle's driving stability but also significantly increases the length and volume of the cargo box. The cargo box adopts a double-layer steel plate structure and is internally sprayed with a wear-resistant coating, which can meet various heavy-load transportation requirements.
3. Suspension and Braking: The front suspension adopts A reinforced double A-arm structure, while the rear suspension is a multi-leaf spring leaf spring suspension. The combination of the two not only provides excellent shock absorption but also offers sufficient support under heavy loads. Both the front and rear are equipped with large-sized 220MM dual hydraulic disc brake systems, along with brake assist devices. Even when fully loaded, this ensures the vehicle has reliable braking performance and guarantees driving safety.
FAQ：
Q1: How many people can a 4-seat 400cc utility side by side carry at most?
A: This vehicle is designed for four passengers. Its spacious interior and comfortable seat layout can meet the needs of multiple people traveling.
Q2: How stable is the vehicle under heavy load?
A: With a super-long wheelbase of 2800mm and a reinforced suspension system, even when fully loaded with goods, it can maintain excellent stability during driving, effectively reducing jolts and roll.
