Parameter list
|
Model |
side by side utility vehicle |
|
Engine Type |
Single-cylinder , 4-stroke , 4 valves |
|
Displacement |
580cc |
|
Horse power |
45.9HP |
|
Fuel Supply |
BOSCH Electronic Fuel Injection |
|
Transmission |
CVTECH CVT/ L-H-N-R-P |
|
Compression ratio |
10.3 :1 |
|
Max Speed |
90 km/h |
|
Drive System |
2WD/4WD/Front differential lock |
|
Front /Rear Suspension |
Double A-arm independent suspension |
|
Front/Rear Shock Absorber |
Coil spring + oil damping |
|
Front/Rear Brakes |
Four wheel hydraulic discs rear wheel parking |
|
Suspension Travel (mm/in) |
F: 166/6.54 R:172/6.77 |
|
Front Tires |
ATV 25 ×8- 12 |
|
Rear Tires |
ATV 25 ×10- 12 |
|
Rim |
Front：12*6 Rear 12*8 |
|
Length x Width x Height (mm/in) |
2200*1180*1270/86.6*46.5*50 |
|
Dry Weight (kg/lbs) |
365 kg/ 804lbs |
|
Gross Weight |
425kgs |
|
Front/Rear Rack Capacity |
F: 20kg / 44lbs R:40kg / 88lbs |
|
Payload |
205kg |
|
Battery capacity |
12V20Ah |
|
Person capacity |
2 |
|
Package size(mm) |
2300×1180×843 |
|
Loading Quantity(Pcs) |
20FCL : 10PCS 40HQ : 30PCS |
Powerful Engine Performance
Boasting a max power of 34kW (at 6750±500r/min) and 45.9HP, the liquid - cooled 580cc engine ensures strong acceleration and sustained power on steep inclines. The BOSCH Electronic Fuel Injection system optimizes fuel delivery, enhancing efficiency and responsiveness across different terrains.
Advanced Suspension & Braking
The double A - arm independent front/rear suspension, paired with coil spring + oil damping shocks, absorbs impacts from rocks and ruts, providing a smooth ride. Four - wheel hydraulic disc brakes (with rear wheel parking) offer reliable stopping power, even when carrying heavy loads.
Impressive Load - Carrying Capability
With a payload of 205kg and a pulling load of 150kg, it handles cargo like camping gear or farm supplies with ease. The front/rear rack capacities (20kg/40kg) add versatility for transporting tools or equipment.
Flexible Drivetrain
The side by side utility vehicle transmission (with L - H - N - R - P gears) and 2WD/4WD system (with front differential lock) adapt to mud, sand, or rocky paths, ensuring traction and control in challenging conditions.
Key Advantages：
Liquid - Cooling Advantage：Unlike air - cooled engines, the liquid - cooled system maintains optimal engine temperature during prolonged use, reducing wear and extending lifespan, critical for intense off - road sessions.
Smart Drivetrain Integration：The combination of CVT transmission and selectable 2WD/4WD with a front differential lock gives it an edge over simpler ATVs, enabling seamless switching between efficiency and rugged capability.
Bosch Fuel Injection Precision：The BOSCH EFI system delivers precise fuel metering, improving throttle response and fuel economy, a premium feature that enhances overall performance.
F&Q：
Q: What's the maximum speed of the side by side utility vehicle?
A: It can reach a max speed of 90 km/h, though actual speed depends on terrain, load, and riding conditions.
Q: How much weight can it carry?
A: The payload is 205kg (including passengers and cargo), and it can pull up to 150kg via the hitch.
Product knowledge：
The liquid - cooling system circulates coolant through the engine, dissipating heat via a radiator, which is essential for preventing overheating in hot climates or during heavy use. The side by side utility vehicle transmission uses a belt - driven system to automatically adjust gear ratios, providing seamless acceleration. The double A - arm suspension allows each wheel to move independently, maintaining tire contact with the ground for better traction. Four - wheel hydraulic disc brakes use fluid pressure to clamp brake pads onto rotors, ensuring strong and consistent stopping power.
