Description

Parameter list

Model	farm utility vehicle
Certification	EPA
Loading information	4units/20″;; 16units/40HQ
Engine type	4 - stroke,Single - Cylinder, Water - cooled
Horse Power	18KW ( 6500rpm) 25HP
Valve Configuration	SOHC
Fuel Delivery System	EFI
Choke System	Automatic
Fuel capacity	9.5L (2.1 Gallon)
Driveline Type	4X2
Transmission	CVT
Final Drive	Shaft - drive
Starting system	Electric start
Ignition system	D.C.D.I
Suspension Front	Double A - arm Suspension
Suspension Rear	Fang power 4 - Link® bar Rear Suspension
Brakes Front&Rear	220MM Front Dual Hydraulic Disk
Front Tread	1250mm ( 49.2 in)
Rear Tread	1150mm ( 45.2in)
Wheelbase	1980mm (78in)
Ground clearance	300mm(11.8in)
Tire(F/R)	25x8 - 12 / 25x10 - 12
Top speed	75km/h
Dry weight	440KGS
Gross weight	540kgs
Vehicle dimension(L×W×H)	2700x1450x1750mm
Packing size	2290x1410x1260mm
COLOR	Green /Sand Yellow
Steel Roof & door	Standard
windshield	Standard
Full bumper	Standard
Roof light bar	Standard

3 1

High cost performance and heavy load capacity

The Mini Truck Quad farm utility vehicle has a cargo box with a size of 700 * 1100 mm and is made of high-strength steel, far exceeding UTVs of the same class. While meeting the demands of heavy-load transportation, the vehicles are affordable, have low usage costs, and are easy to maintain and repair, offering users an extremely high cost-performance ratio.

Customized expansion potential

The vehicle body reserves a large number of modification interfaces and Spaces. Users can easily install various accessories according to their own needs, such as winches, luggage racks, audio systems, LED lights, etc., to transform the vehicle into a dedicated multi-functional vehicle and meet personalized usage requirements in different scenarios.

3 3

3 5

Excellent ergonomic design

The cockpit space of the Four Wheel farm utility vehicle is spacious. The seats are ergonomically designed to provide good support for the waist and back, and it is not easy to get tired even after long driving. The layout of the operation handle and the pedal is reasonable, making the operation easy and convenient. Even first-time drivers can quickly get the hang of it.

Product Application Contexts

Agricultural Operations: The farm utility vehicle excels in intra-farm transportation of crops and supplies, along with efficient farmland patrols, enhancing productivity for large-scale farming operations.

Off-Road Expeditions: Engineered for rugged terrain, this vehicle delivers exceptional off-road performance in mountain forests, sandy deserts, and challenging landscapes, catering to adventure enthusiasts.

Construction Site Logistics: The 400cc Mini Truck farm utility vehicle optimizes material transport on small job sites, navigating tight passages with agility to streamline construction workflows.

Technical Architecture

Propulsion System:
Both models feature a 4-stroke single-cylinder liquid-cooled engine with advanced heat dissipation, delivering 18KW (25HP) at 6500rpm and a 10.0:1 compression ratio. Their EFI systems adapt to environmental changes, improving fuel efficiency by 15% compared to traditional setups.

Chassis & Suspension:
The farm utility vehicle utilizes a high-strength frame for durability in open terrain, while the 400cc Mini Truck farm utility vehicle employs a compact chassis for maneuverability in confined spaces. Both offer adjustable suspensions for tailored ride comfort.

Electrical System:
Equipped with waterproof wiring and a 12V 12ah battery, these vehicles ensure reliable operation in harsh conditions, with the D.C.D.I ignition system enhancing start-up performance.

Common Inquiries

Q: How do these models differ in application?
A: The farm utility vehicle is designed for broad agricultural and off-road use, while the 400cc Mini Truck farm utility vehicle specializes in compact-scale tasks like small-site construction or narrow-row farming.
